The large enclosures in the VX25 series offer a good level of shielding across a broad frequency range, even in the standard version. For increased EMC requirements, Rittal’s VX25 enclosure is also available in a high RF attenuation version.
- Article number:
- VX 8807.010
- Design
- EMC version
- Product description
- The large enclosures in the VX25 series offer a good level of shielding across a broad frequency range, even in the standard version. For increased EMC requirements, Rittal’s VX25 enclosure is also available in a high RF attenuation version.
- Material
- Enclosure frame: Sheet steel with zinc magnesium coating, 1.5 mm
Roof: Sheet steel with zinc magnesium coating, 1.5 mm
Door: Sheet steel with zinc magnesium coating, 2.0 mm
Rear panel: Sheet steel with zinc magnesium coating, 1.5 mm
Gland plates: Sheet steel, 1.5 mm
Mounting plate: Sheet steel, 3.0 mm - Surface finish
- Enclosure frame: Uncoated
Door, rear panel and roof: Spray-finished on the outside and paint-free on the inside
Gland plates: Zinc-plated
Mounting plate: Zinc-plated - Colour
- RAL 7035
- Supply includes
- Enclosure frame
Door(s)
Door hinged on the right, may be swapped to the left
Rear panel
Roof plate
Gland plates
Mounting plate
Lock: 3 mm double-bit
2 punched rails 18 x 39 mm - Protection category to IEC 60 529
- IP 55
- Protection category NEMA
- NEMA 1
- NEMA 12
- Type rating to UL 50E
- Type 1
- Type 12
- Dimensions
- Width: 800 mm
Height: 2,000 mm
Depth: 600 mm - Number of doors
- 1
- Note
- For bayed enclosures, the EMC shielding seal is required
- Packs of
- 1 pc(s).
- Weight/pack
- 130 kg
- PCF/PU (Cradle-to-Gate)
- 320.3 kg CO2 eq (Cat B)
- Note on the PCF class
- Category B: PCF value (cradle-to-gate) approximated based on product weight and self-declared
- EAN
- 4028177924574
- ETIM 7.0
- EC000261
- ECLASS 8.0
- 27180101
- Product description
- VX Baying enclosure system, WHD: 800x2000x600 mm, Sheet steel, EMC version, with mounting plate, single door at the front
