Simply knock out the holes for the cable glands using a screwdriver, IP 66 when mounting in the usual position at the bottom.
- Article number:
- SZ 2561.100
- Product description
- Simply knock out the holes for the cable glands using a screwdriver.
- Material
- Sheet steel
- Colour
- RAL 7035
- Note
- The allocation of gland plate sizes is indicated on the relevant enclosures
- No. of metric knockouts
- 9 x M20
4 x M25
2 x M32 - Dimensions
- Width: 330 mm
Depth: 90 mm - To fit
- Enclosure type: AE
- Gland plate
- Size: 3
- Protection category to IEC 60 529
- IP 66 when mounting in the usual position at the bottom
- Number knockouts
- 9
4
2 - Metric diameter
- M20
- M25
- M32
- Packs of
- 1 pc(s).
- Weight/pack
- 0.36 kg
- Customs tariff number
- 73269098
- EAN
- 4028177390850
- ETIM 8
- EC000211
- ETIM 7.0
- EC000211
- ECLASS 8.0
- 27142421
- Product description
- SZ Metal gland plate, with metric knock-outs, WD: 330×90 mm, size: 3
