Ex enclosures with hinged door, plastic
- Article number:
- AX 9207.100
- Design
- Ex enclosures
- Material
- Fibre-glass-reinforced unsaturated polyester, surface resistance: < 10⁹ Ω
Door: Fibreglass-reinforced unsaturated polyester, surface resistance: < 10⁹ Ω, bonded all-round silicone seal
Mounting plate: Sheet steel, zinc-plated - Colour
- RAL 9011
- Supply includes
- Enclosure
Door
Mounting plate - Dimensions
- Width: 500 mm
Height: 500 mm
Depth: 300 mm - Dimensions mounting plate (W x H)
- 405 mm x 425 mm
- Material thickness of mounting plate
- 3 mm
- Certificate IEC EX PTB 10.0011U
- Yes
- Certificate PTB 03 ATEX 1011U
- Yes
- Lock
- Number of locks: 2
- IP protection category to IEC 60 529
- IP 65
- Protection category NEMA
- Type 1
- Type 3R
- Type 3RX
- Type 4
- Type 4X
- Type 12
- IK Code
- IK09
- Packs of
- 1 pc(s).
- Weight/pack
- 14.8 kg
- PCF/PU (Cradle-to-Gate)
- 74.4 kg CO2 eq (Cat B)
- Note on the PCF class
- Category B: PCF value (cradle-to-gate) approximated based on product weight and self-declared
- Customs tariff number
- 94037000
- EAN
- 4028177952119
- ETIM 7.0
- EC002503
- ECLASS 8.0
- 27180502
- Product description
- AX Ex enclosure, WHD: 500x500x300 mm, fibreglass-reinforced unsaturated polyester, with mounting plate, empty enclosure with hinged door
